Details
We made the Chameleon for riders who like to sculpt their ideal bike, and aren’t afraid to experiment. Whether 29er or mixed, geared or fixed, multiple major configuration transformations are made easy via the interchangeable dropouts. The low slung top tube and progressive geometry means this bike blends into whatever surroundings you place it. From raucous short-cuts across town to skipping the city altogether. It turns itself to trail exploration with the flip of an Allen key, thanks to the triple-bolt cargo cage mount under the downtube and standard bottle mount within the frame.
Design Details:
Aluminum frame
The Chameleon reinvents itself yet again, returning to the no-nonsense alu roots that make it our most versatile hard-working hardtail of all time.
MX or 29
Options for full 29 or MX setups means you can opt for speed and comfort for hauling or quick and nimble handling.
Single speed or gears
Adjustable dropouts make it a multi-geared trail charger to single-speed racer to bikepacking mule...and pretty much anything imaginable in between.
A Mule That Rules
Tougher and stronger than any race horse, the Chameleon blends stamina with agility to create a whole new kind of beast. A triple-bolt cargo cage mount under the downtube and additional mount within the frame ensures the Chameleon is ready to play wherever The Wild Things Are.
Fun-loving, shreddy spirit
The low slung top tube and more progressive geometry (65.5-degree head-angle and longer reach) provides all-trail capability.
Lifetime warranty
Built to last many lifetimes and supported by the legendary Santa Cruz rider support.
S | M | L | XL | |
---|---|---|---|---|
Reach | 420 | 445 | 465 | 490 |
Stack | 620.1 | 629.2 | 638.2 | 647.3 |
Head Tube Angle | 65.0° | 65.0° | 65.0° | 65.0° |
Seat Tube Length | 380 | 405 | 430 | 460 |
Front Center | 729.4 | 758.6 | 782.8 | 812.1 |
BB Height | 315 | 315 | 315 | 315 |
BB Drop | 56/40 | 56/40 | 56/40 | 56/40 |
Wheelbase | 1154.4 | 1183.6 | 1207.8 | 1237.1 |
Rear Center | 425-437 | 425-437 | 425-437 | 425-437 |
Head Tube Length | 100 | 110 | 120 | 130 |
Top Tube Length | 596.1 | 621.3 | 643.4 | 668.8 |
Seat Tube Angle | 74.1° | 74.3° | 74.4° | 74.6° |
Standover Height | 682 | 682 | 686 | 708 |
S | M | L | XL |
---|---|---|---|
5'0" - 5'5" | 5'5" - 5'10" | 5'10" - 6'1" | 6'1" - 6'6" |
Specs
Fork | FOX 34 Float Performance, 130mm |
---|---|
Hubs |
Front Hub: DT Swiss 370, 15x110, 6-Bolt, 28h Rear Hub: DT Swis 370, 12x148, XD, 6-Bolt, 36t, 28h |
Rims | RaceFace AR Offeset 30, 29" |
Stem | Burgtec Enduro MK3, 42mm |
Chain | SRAM GX Eagle, 12spd |
Frame | Aluminum |
Tires |
Front Tire: Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO Rear Tire: Maxxis Aggressor 29"x2.5"WT, EXO |
Brakes | SRAM G2 R |
Rotors | Avid Centerline, 180mm |
Saddle | WTB Silverado Medium, Promo |
Headset | Cane Creek 40 IS Integrated Headset |
Crankset | SRAM GX Eagle 148 DUB 32t |
Seatpost | OneUp V2 Dropper Post, 31.6 |
Shifters | SRAM GX Eagle, 12spd |
Handlebars | Burgtec Alloy Bar |
Tape/Grips | Santa Cruz Bicycles House Grips |
Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
Rear Derailleur | SRAM GX Eagle, 12spd |
Cassette/Freewheel | SRAM XG1275 Eagle, 12spd, 10-50t |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Black / Medium / 29-inch | 192219363134 | 58-24248-109-3B 58-24248-109-3-808-011201 | |
Black / Large / 29-inch | 192219363158 | 58-24248-109-4B 58-24248-109-4-808-011201 | 210000084455 |
Black / Small / 29-inch | 192219363110 | 58-24248-109-2B 58-24248-109-2-808-011201 | |
Black / X-Large / 29-inch | 192219363172 | 58-24248-109-5B 58-24248-109-5-808-011201 |
